The CCU supports not only UHD and HD simultaneous output, but also enables high-speed output*1 up to 240p in HD mode to be performed simultaneously with standard (1x) output, while still having a compact size.
Features
Power Supply:12 V DC (DC input range: 10 V - 16 V DC), 42 V - 57 V DC (PoE+ power supply)
Power Consumption: 1.6 A (Power supply: 12 V DC) 0.6 A (PoE+ power supply)
Operating Temperature: 0°C to 40°C (32°F to 140°F)
Humidity:90% or less
Storage Temperature: -20°C to 60°C (-4°F to 140°F)
Weight Approx.: 4.0 kg (8.82 lb)
Dimensions (W x H x D): 482 mm x 222 mm x 81.5 mm (18-31/32 inches x 8-3/4 inches x 3-7/32 inches) (Including mounting brackets and dial heights)
Adjustment Functions: Scene file, ND filter, CC filter, Color temperature (COLOR TEMP), Master gain (MASTER GAIN),
Shutter (SHUTTER), Master pedestal (MPED), Iris (IRIS), Camera selection
CCU Control: RS422 or IP
Maximum Cable Length: When CCU is connected: 50 m (164 ft)
